Go to the source code of this file.
|
|
#define | ROM_FUNC_POPCOUNT32 ROM_TABLE_CODE('P', '3') |
| |
|
#define | ROM_FUNC_REVERSE32 ROM_TABLE_CODE('R', '3') |
| |
|
#define | ROM_FUNC_CLZ32 ROM_TABLE_CODE('L', '3') |
| |
|
#define | ROM_FUNC_CTZ32 ROM_TABLE_CODE('T', '3') |
| |
|
#define | ROM_FUNC_MEMSET ROM_TABLE_CODE('M', 'S') |
| |
|
#define | ROM_FUNC_MEMSET4 ROM_TABLE_CODE('S', '4') |
| |
|
#define | ROM_FUNC_MEMCPY ROM_TABLE_CODE('M', 'C') |
| |
|
#define | ROM_FUNC_MEMCPY44 ROM_TABLE_CODE('C', '4') |
| |
|
#define | ROM_FUNC_RESET_USB_BOOT ROM_TABLE_CODE('U', 'B') |
| |
|
#define | ROM_FUNC_CONNECT_INTERNAL_FLASH ROM_TABLE_CODE('I', 'F') |
| |
|
#define | ROM_FUNC_FLASH_EXIT_XIP ROM_TABLE_CODE('E', 'X') |
| |
|
#define | ROM_FUNC_FLASH_RANGE_ERASE ROM_TABLE_CODE('R', 'E') |
| |
|
#define | ROM_FUNC_FLASH_RANGE_PROGRAM ROM_TABLE_CODE('R', 'P') |
| |
|
#define | ROM_FUNC_FLASH_FLUSH_CACHE ROM_TABLE_CODE('F', 'C') |
| |
|
#define | ROM_FUNC_FLASH_ENTER_CMD_XIP ROM_TABLE_CODE('C', 'X') |
| |
| #define | ROM_TABLE_CODE(c1, c2) ((c1) | ((c2) << 8)) |
| | Return a bootrom lookup code based on two ASCII charactersThese codes are uses to lookup data or function addresses in the bootrom. More...
|
| |
|
#define | rom_hword_as_ptr(rom_address) (void *)(uintptr_t)(*(uint16_t *)(uintptr_t)(rom_address)) |
| |
|
|
typedef uint32_t(* | rom_popcount32_fn) (uint32_t) |
| |
|
typedef uint32_t(* | rom_reverse32_fn) (uint32_t) |
| |
|
typedef uint32_t(* | rom_clz32_fn) (uint32_t) |
| |
|
typedef uint32_t(* | rom_ctz32_fn) (uint32_t) |
| |
|
typedef uint8_t *(* | rom_memset_fn) (uint8_t *, uint8_t, uint32_t) |
| |
|
typedef uint32_t *(* | rom_memset4_fn) (uint32_t *, uint8_t, uint32_t) |
| |
|
typedef uint32_t *(* | rom_memcpy_fn) (uint8_t *, const uint8_t *, uint32_t) |
| |
|
typedef uint32_t *(* | rom_memcpy44_fn) (uint32_t *, const uint32_t *, uint32_t) |
| |
|
typedef void(* | rom_reset_usb_boot_fn) (uint32_t, uint32_t) |
| |
|
typedef rom_reset_usb_boot_fn | reset_usb_boot_fn |
| |
|
typedef void(* | rom_connect_internal_flash_fn) (void) |
| |
|
typedef void(* | rom_flash_exit_xip_fn) (void) |
| |
|
typedef void(* | rom_flash_range_erase_fn) (uint32_t, size_t, uint32_t, uint8_t) |
| |
|
typedef void(* | rom_flash_range_program_fn) (uint32_t, const uint8_t *, size_t) |
| |
|
typedef void(* | rom_flash_flush_cache_fn) (void) |
| |
|
typedef void(* | rom_flash_enter_cmd_xip_fn) (void) |
| |
|
typedef void *(* | rom_table_lookup_fn) (uint16_t *table, uint32_t code) |
| |
|
| static uint32_t | rom_table_code (uint8_t c1, uint8_t c2) |
| | Return a bootrom lookup code based on two ASCII charactersThese codes are uses to lookup data or function addresses in the bootrom. More...
|
| |
| void * | rom_func_lookup (uint32_t code) |
| | Lookup a bootrom function by code. More...
|
| |
| void * | rom_data_lookup (uint32_t code) |
| | Lookup a bootrom address by code. More...
|
| |
| bool | rom_funcs_lookup (uint32_t *table, unsigned int count) |
| | Helper function to lookup the addresses of multiple bootrom functionsThis method looks up the 'codes' in the table, and convert each table entry to the looked up function pointer, if there is a function for that code in the bootrom. More...
|
| |
| static __force_inline void * | rom_func_lookup_inline (uint32_t code) |
| | Lookup a bootrom function by code. This method is forcibly inlined into the caller for FLASH/RAM sensitive code usage. More...
|
| |
| static void | reset_usb_boot (uint32_t usb_activity_gpio_pin_mask, uint32_t disable_interface_mask) |
| | Reboot the device into BOOTSEL modeThis function reboots the device into the BOOTSEL mode ('usb boot"). More...
|
| |
v1.5.0
